XP3i Digital Pressure Gauge

Digital Pressure Gauge, Digital Test Gauge XP3i
High Accuracy Digital Test Gauge - Ultra Rugged

Ultra rugged, intrinsically safe, digital test gauge with “0.05% of reading”, “0.02% of full scale”, or “0.05% of full scale” accuracy levels. Carry a single XP3i digital pressure gauge to cover a wide pressure range and replace multiple “of scale” gauges. If a recording of a pressure test is required, add the DataLoggerXP upgrade to open a wide range of features and functions.

Now with USB-C and Bluetooth connections, a free mobile app, and a cloud software service, you can share stored files with any colleague with internet access.

• Ranges up to 15 000 psi
• Marine grade enclosure resists corrosion (MIL-STD 810)
• Accuracy not affected from -20 to 50°C (increased range from the XP2i)
• Replaces 5 or more test gauges
• Fast pressure safety valve (PSV) mode
• Easy to use – No Menu. No Manual? No Problem!
• Includes calibration reminders and alerts - See our digital pressure gauge application note for details

With a Bluetooth connection, you can:

• Connect in a hazardous environment while retaining intrinsically safe ratings
• Mount the XP3i in hard-to-reach locations and connect from a safe area
• Avoid inclement weather by connecting to the XP3i from a climate-controlled office or vehicle
• Forgot your communication cable? Are drivers not installed? Is the cable damaged? All of these problems go away with a Bluetooth connection

With the optional DataLoggerXP upgrade

• Record over 200 million data points
• Over an entire year of continuous recording time
• Start and stop logging runs from your phone or the gauge
• Download data using a USB connection and a computer or through Bluetooth and the mobile app

With the new CrystalControlWeb cloud software (Free)

• Upload stored data from your computer
• Upload stored data from a file – wirelessly downloaded using your app
• Share stored data with anybody in your organization
• Grant user access to your organization through a license key
• Graph your stored data
• Customized graph details like line color, axis minimum and maximums, and run and test names
• Configure the settings on your XP3i
• Download data to spreadsheets or secure, tamper-proof pdf files

For more information, please contact us.


  • Documentation +

  • Video +

    ProductVideoMessage

  • Options +

      • AMETEKCal Discounted three year calibration program.
      • -DD Dual Line Display – Adds a second line to the display which can be set to indicate peaks, average, leak rate, or data logging details (if upgraded to -DL). Great for relief valve or leak testing.
      • -DL DataLoggerXP – Allows you to store and record over 200 million measurements at a time. Our CrystalControlWeb service stores records in the cloud and allow you to create, share, and export reports. The XP3i, once authorized, performs all of the actual data collection.
      • -S2 0.02 % of full scale accuracy. See Data Sheets for complete specifications.
      • -S5 0.05 % of full scale accuracy. See Data Sheets for complete specifications.
      • -BSP G ¼ B Parallel Pressure Fitting
      • -M20 M20 x 1.5 Male CPF Adapter
    • System A & B Pump Systems
      System A
      • AHX Pump System: Includes a T-970 pneumatic hand pump (0 to 580 psi / 40 bar)
      • AXX Pump System: Includes a T-960 pneumatic hand pump (0 to 30 psi / 2 bar)
    • System A & B Pump Systems
      System B
      • BHX Pump System: Includes a T-975 pneumatic hand pump (-25 inHg to 580 psi / - 0.91 to 40 bar)
      • BXX Pump System: Includes a T-965 pneumatic hand pump (-25 inHg to 30 psi / - 0.91 to 2 bar)
    • System C Pump System
      System C
      • CHX Pump System: Includes a T-620H Hydraulic Hand Pump (0 to 5000 psi)
      • CXX Pump System: Includes a T-620 Hydraulic Hand Pump (0 to 3000 psi)
    • System D Pump System
      System D
      • DOX Pump System: Includes a P-018-CPF hydraulic screw pump (0 to 5000 psi, for use with oil)
      • DWX Pump System: Includes a P-018-CPF hydraulic screw pump (0 to 5000 psi, for use with water)
    • System E
      System E
      • EOX Pump System: Includes a P-014 hydraulic bench top pump (0 to 10 000 psi, for use with oil)
    • System F Pump System
      System F
      • FOV Pump System: Includes a T-1 hydraulic bench top pump (0 to 15 000 psi, for use with oil)
      • FWV Pump System: Includes a T-1 hydraulic bench top pump (0 to 15 000 psi, for use with water)
    • System G Pump Systems
      System G
      • GOX Pump System: Includes a GaugeCalHP hydraulic pressure comparator (0 to 15 000 psi, for use with oil)
      • GWX Pump System: Includes a GaugeCalHP hydraulic pressure comparator (0 to 15 000 psi, for use with water)
    • System H Pump Systems
      System H
      • HOX Pump System: Includes a T-975 Pneumatic Hand Pump (-25 inHg to 580 psi / - 0.91 to 40 bar) and a T-620H Hydraulic Hand Pump (0 to 5000 psi / 350 bar)

  • Accessories +

      • 5203 Magnetic Hanging Strap for XP3i, XP2i, m1, HPC40 Series, and HPC50 Series
      • 7095 XP3i Protective Boot – Protective boot to increase shock resistance. Intrinsically Safe Rated.
      • 3009 Hard Carrying Case – egg crate foam. External Dimensions: 14 x 11 x 3.2 inches
      • 2888 Weatherproof Hard Carrying Case – die cut foam. Internal Dimensions: 16.8 × 11.2 × 6.1 inches
      • 6885 USB Cable USB C to USB A. WARNING: Do not use USB interface within a hazardous atmosphere.
      • 7190 USB Universal Adapter, Wall Mount, USB-A. In the event of a power failure, an XP3i will automatically switch from its batteries to the Wall Mount Adapter.

  • Software +

    • CrystalControlWeb

      CrystalControlWeb (Free) – Access CCW through any web browser, making your XP3i data available to your colleagues worldwide within minutes of collecting it.

    • CrystalConnect

      CrystalConnect (Free) – Download the CrystalConnect Mobile application from the iOS App Store to connect via Bluetooth to your XP3i. Use the app to download stored data, view live data, start and stop logging runs.

    • UnitCalc

      UnitCalc (Free) – Easy pressure unit calculator. Displays all conversion factors and converted units at the same time. UnitCalc also calculates Head Correction, Gravity Correction, and Air Density

  • Release Notes +

      • Version 1.2.0 05-Dec-25. Fixed: 1) An improvement to prevent the occurrence of ERR 8 and ERR 12, 2) Addresses scenarios where the XP3i could crash while logging with DataLoggerXP. Added Features: 1) The serial number is displayed at the end of the settings overview, 2) Enhanced data protection to ensure data is not lost during low battery conditions.
      • Version 1.1.1 20-Mar-25. Fixed: 1) The XP3i will no longer turn on after 30 minutes when calibration due and warning feature is enabled, 2) The XP3i will no longer turn off when a Bluetooth connection is active even if the Auto-off time is set, 3) Improved the display's indication of an over pressure event.
      • Version 1.1.0 20-Nov-24. Added Features: 1) 25% greater battery life when using Bluetooth, 2) XP3i will always advertise Bluetooth connectivity once Bluetooth is turned on without degrading battery life, 3) Improved log file upload reliability and speed, 4) Various improvements for current and future versions of CrystalConnect, 5) Support for new 15KPSI (and equivalent) models. Fixed: 1) Numerous fixes and improvements to ultra-low power (ULP) mode improving stability when recording.
      • Version 1.0.1 24-Jun-24. Added Features: 1) Holding the Power button for five seconds when an error code is displayed will power cycle the XP3i. Fixed: 1) XP3i now powers on when USB is connected, 2) XP3i will no longer reset if connected to CrystalConnect while Bluetooth is turned off.
      • Version 1.0.0 24-May-24. Initial Release
